|DoorKing 1808 Telephone Entry
The model 1808 is a small compact telephone entry system that is loaded with features. The distinctive
styling of the 1808 makes it ideal for small residential or commercial applications. And, by adding the
optional built in directory, the 1808 is ideal for small multi-home gated community applications. The 1808
is available in surface mount style only. Visitors are identified by voice communication via the
telephone. Access is granted by pressing "9" on your touch tone telephone, or access can be denied by
simply hanging up.
The 1808 is available with or without a small, built-in directory.
Programmable directory codes (1-4 digits).
10 and 11-digit dialing capability.
Two special inputs can be programmed for relay
activation or to dial out a preprogrammed phone
5-digit entry codes for special needs.
LED lighted keypad.
Built-in time clock.
Hold open time zones.
Entry code time zones.
"Flash" entry codes.
Stores up to 1000 telephone numbers.
Full duplex commnication.
4-digit entry codes; same number as memory
Six, 5-digit entry codes.
10 area codes.
16 VAC, 20 VA (250 ma) power transformer
Ringer equivalence: 0.0 A.
Jack type: RJ11C or W.
FCC (US): DUF6VT-12874-OT-0
DOC (CAN): 1736 4507 A
Complies with UL 294; ETL Listed.
Surface mount dimensions: 7.375"H x 11"W x
|ACCESSORIES AVAILABLE FOR THIS MODEL
Back up battery.
Heater kit (recommended when temperatures
routinely fall below 10F / -12C).
Fluorescent light kit.
* Provides visitor access control in
residential or commercial
* Visitors use the 1808 to
communicate with a resident, who
can then grant or deny them access
from their touchtone phone
* Provides service for up to 1000
* Programmable directory codes
can be set from 1 to 4 digits
* Ideal for residential, multihome
applications with limited space, or
do not require a directory, or where
a separate directory exists
|BFT Cell Phone Entry with
