|DoorKing 1837 - PC Programmable
The Model 1837 is an ideal telephone entry and access control system suited for medium to large apartment and gated
community applications as well as office buildings and industrial sites. The eight-line LCD display features big 1/2-inch
characters for easy viewing and your personalized message appears on the screen when the system is not in use. Our
unique "One Touch" CALL button makes this system one of the easiest to use on the market today! The built-in electronic
directory, easy to use Remote Account Manager programming software, card reader interface and expandability options
make this unit an ideal choice for those applications with a large number of system users and entry locations. Up to 16 card
readers can be interfaced with the 1837 to provide access control. Additionally, our elevator control module restricts
which floors a guest or system users have access to, making it an ideal system for high rise buildings. For additional
security, the 1837 allows you to monitor activity AS IT HAPPENS on your computer display (requires RS-232 connection), and
with our anti-pass back memory, you can enable a TRUE anti-pass back system in one of three different configurations;
passive, active and trap.
The 1837 is available in three distinct styles:
Surface, flush or wall mount – specify which
Stainless steel case (available on surface mount only).
Memory size: 125, 250, 500, 3000 – choose one.
Tracker expansion boards.
Elevator control boards.
PC Programmable via the internet (using DKS server
connection), modem or RS-232. Remote Account
Manager and Transaction Analysis software included.
Large easy to use A and Z scroll buttons.
One Touch "CALL" button.
Built-in eight-line LCD directory display.
Programmable directory codes (1-4 digits).
10 and 11-digit dialing capability.
Interfaces with 2 card readers - expandable to 16
with tracker expansion board(s)
Live transactions (requires RS-232 connection).
8000 event transaction buffer.
Elevator control - requires elevator control boards(s)
31 Security (permission) levels.
Database import/export capability.
LED Lighted keypad.
Hold open time zones.
Entry code time zones.
Built-in postal lock provision.
Note 1: Requires Elevator Control Board(s).
Note 2: Requires Tracker Expansion Board(s).
True Full Duplex communication.
Stores up to 3000 telephone numbers and names. Memory sizes
available: 125, 250, 500, 3000. Specify requirement when ordering.
Transaction buffer stores last 8000 events.
Stores up to 8000 access card codes - dependent on system memory.
31 security (permission) levels, 29 programmable with 4 time zones
8 hold open time zones.
Three anti-pass back configurations: passive, active and trap.
Elevator control (note 1) for up to 4 elevators, each serving 64 floors.
Expandable (note 2) to control up to 16 entry points.
4-digit entry codes, one for each telephone number.
3 form "C" dry contact relays.
Eight-line directory display uses super-twist LCD with 1/2-inch
Requires touch-tone, loop-start central office phone line.
16 VAC, 20 VA and 16 VAC, 50 VA power transformers supplied.
FCC (US): DUF6VT-12874-OT-T
DOC (CAN): 1736 4528 A
Compliant with UL 294. ETL listed.
Dimensions Surface Mount: 13"H x 11.25"W x 4.75"D.
Dimensions Flush Mount: 13.5"H x 12"W x 2.5"D.
Dimensions Wall Mount: 15"H x 13.25"W x 3.5"D.
|ACCESSORIES AVAILABLE FOR THIS MODEL
Surface mount trim ring (use with surface mount units only)
Flush mount installation kit (required with flush mount units).
ADA compliant handset.
Fluorescent light kit.
Back up battery.
Heater kit (recommended when temperatures routinely fall below 10F / -12C).
Color or BW CCTV camera (may require additional CCTV equipment).
