DoorKing Sliding Gate Opener 9100
Commercial  Gate Operator
The Doorking 9100 operator is designed to operate vehicular slide gates in
residential and commercial applications.   The Doorking 9100 is designed so
that it can easily be mounted in the front, center or rear of the gate without
any costly and time consuming field modifications.   In addition, the operator
can be pad or post mounted to meet any installation requirements.
Doorking 9100 Gate Operator / Openers
ADVANCED FEATURES
Partial-open feature.
Anti-tailgating feature.
Gate tracker reporting output.
Ports for plug-in loop detectors.
Two convenience outlets.
Fail-safe release (fail-secure optional).
Programming switches.
Built-in reset switch.
Built-in power On/Off switch.

Doorking 9100 Gate Openers
Maximum gate length 30-feet.
Maximum gate weight 1000 pounds*.   (*Assumes gate is on level ground, in good condition with properly adjusted
hardware.   Other external factors may affect the performance of the gate operator.)
115 VAC, 5.4 Amps.
Operator is shipped with chain brackets and 20-feet of #41 chain.
Class I, II,   III and IV applications.
Compliant with UL 325 and 991.   ETL Listed.   (Note: To be compliant with UL 325 and industry safety guidelines, a
secondary entrapment prevention device(s) is required to be installed with this gate operator.   Your professional
DKS system installer can provide you with more details on these devices and on current industry safety standards.)
Dimensions: 12"W x 24"H x 11.5"D

Doorking 9100 Gate Operators
OPTIONS AVAILABLE WITH THIS OPERATOR
#40 chain.
Nickel plated chain.
Stainless steel chain.
Plug-in loop detectors.
Heater kit for cold environments.
Base plate to post mount this operator (does not include posts).
Surge suppressors.
Pre-form Loop pave over OR saw cut Vehicle detection and Protection
wired with XLPE insulated wire
and are placed in the roadway
prior to concrete being poured.
Loop detector single or dual vehicle detection plugs ins easy instalation
plug-in loop detectors
simplify installation and are
used for vehicle protection.
Remote controls from Multi-code
Remote controls from linear
Remote controls from liftmaster
Remote control key chain mini 1 button and 2 buttons
mini remote controls
Select from the top brand of
signal Receiver Click on image
Multi-code receivers
Liftmaster Receivers and other brands available click on image
Mega code from linear select from top brand of radio receivers
Need other accessories just click
Phone entry
Intercom
Remotes
Receivers
Gate Accessories
