The Delta 3 GRD is a 1-Channel Gate Receiver designed for use with automatic gate operators or systems where a remote antenna is needed. The receiver uses the Delta-3 radio format, with 256 possible codes, set by dipswitch. |
|
The Delta 3 GRD-2 is a 2-channel Gate Receiver designed for use with automatic gate operators or systems where a remote antenna is needed. The GRD-2 can operate two gates, one gate and an obstacle sensor, or channel one can open the gate and channel two can close the gate. The receiver uses the Delta-3 radio format, with 256 possible codes for each channel, set by dipswitch. |
Mega-Code MDRG: 1-Channel Gate Receiver 24-volt, single-channel, three-terminal receiver, 10 code capacity, MegaCode format. Features •Activates one device •Stores up to 10 transmitter codes •Wire lead antenna •Mounting bracket supplied •Power: 24 Vac/Vdc •Frequency: 318 MHz •Codes: 1,000,000+ (factory precoded) •Memory: storage for up to 10 transmitters •Dimensions: 5.5 x 1.25 x 4 inches •Order number: DNR00071 |
Mega Code MGR: 1-Channel Gate Receiver The MegaCode series of digital receivers are wireless radio controls designed for use with automatic gate openers. The MegaCode radio format provides unparalleled security. The transmitter and receiver can be programmed to more than a million different codes. Features •Activates one gate or device •Stores up to 40 transmitter codes •Supplied with F-connector and whip antenna •Mounting bracket supplied •Power: 24 Vac/Vdc •Frequency: 318 MHz •Codes: 1,000,000+ (factory precoded) •Memory: storage for up to 40 transmitters •Dimensions: 5.5 x 1.25 x 4 inches •Order number: DNR00073 |
Mega-Code |
Linear AM-RRR Remote Radio Receiver The Model AM-RRR Remote Radio Receiver is designed for use with Linear's access control systems. The AM-RRR functions as a remote device that extends the radio range or supplies localized radio reception. Three antenna types can be used with this receiver. |
Linear RGR Remote Genie Receiver The Model RGR Remote Genie Receiver is designed for use with Linear's AE1000Plus, AE2000Plus, and AM3Plus access control systems. The RGR functions as a remote device that supports reception of Linear's GT-30 and GT-31 transmitters. |
Linear WOR Wiegand Output Receiver The Model WOR Wiegand Output Receiver is designed for use as an access control interface for Linear's block coded digital transmitters. The unit receives signals from transmitters, adds a facility code to the data, and sends the information to the Wiegand input of the access control panel via a 5-wire connection. |
Linear AP-5 Access Controller - Receiver Dual-portal access control system, built-in radio receiver, supports 480 block coded transmitters or 238 individual transmitters/wireless keypad entry codes and six MGT obstacle transmitters, three relays, programmable access or obstacle output |
Linear AP-4 Gate Access Receiver Ideal for gated communities, parking facilities, and industrial sites. Easy to set-up and use — up to 480 remotes can be programmed with a few keystrokes. Easy to add, suspend, and delete transmitters through programming mode — no transmitter dip switches to set. |
Multi-Code 109920 1-Channel, 110V, Gate Receiver is designed for use in gate operator applications. An 11-inch wire whip antenna is included for local reception. The whip antenna connects to the receiver's Type-F antenna connector. |
Multi-Code 109020 1-Channel Receiver is designed for use in residential garage door operator applications. Typically the receiver mounts directly to the three terminals on the door operator. An 11-inch wire antenna extends from the receiver. 300MHZ |
Multi-Code 109950 is a dual frequency receiver. An internal jumper selects either 300 MHz or 310 MHz operating frequency. The 300 MHz frequency is compatible with standard Multi-Code transmitters, the 310 MHz frequency is compatible with the Stanley version Multi-Code transmitters. |
Multi-Code 302101 2-Channel Heavy-Duty Gate Receiver is designed for use in gate operator applications. The receiver is housed in a heavy-duty metal cabinet. The cabinet meets NEMA 13 and JIC specifications and features a sealed strain relief bushing for wiring |
Multi-Code 302850 2-Channel, 12-24V, Gate Receiver is designed for use in gate operator applications. An 11-inch wire whip antenna is included for local reception. The whip antenna connects to the receiver's Type-F antenna connector. |
Multi-Code 105104 Gate Safety Edge Transmitter is for adding obstacle sensing for motorized gates or barrier arms. Using a safety edge transmitter is more economical and discrete than the traditional coiled cord connection method. |
Multi-Code 302210 Gate Safety Edge Transmitter is for adding obstacle sensing for motorized gates or barrier arms. Using a safety edge transmitter is more economical and discrete than the traditional coiled cord connection method. |
Multi-Code 309013 1-Channel Receiver is designed for use in residential garage door operator applications. Typically the receiver mounts directly to the three terminals on the door operator. An 11-inch wire antenna extends from the receiver. 310MHZ |
