FAAC is the undisputed world leader in automated systems for opening gates, doors and garage doors. We produce
automatic movement operators for gates, garage doors, barriers, rolling shutters, glazed doors, swing shutters, and access
control systems, with countless solutions for intensive, heavy commercial uses as well as for residential applications.
FAAC's hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet operation for even
the largest gated communities. These operators have met rigorous UL-325 safety standard testing, thus reducing a
community's liability.
automatic movement operators for gates, garage doors, barriers, rolling shutters, glazed doors, swing shutters, and access
control systems, with countless solutions for intensive, heavy commercial uses as well as for residential applications.
FAAC's hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet operation for even
the largest gated communities. These operators have met rigorous UL-325 safety standard testing, thus reducing a
community's liability.
| Specifically designed for light - medium traffic applications, the FAAC 615 can raise beams from 6 1/2 to 13 feet (2 to 4 meters) in 3 - 8 seconds. With a 50% duty cycle, the 615 is ideal for certain residential and commercial uses. |
| FAAC 615 Hydraulic Arm Barrier Gate Operator Specifications * Duty type light to moderate volume traffic control, standard width entrances * Duty cycle at 72(F (24(C) 50% motor run time * Opening time 3-8 sec (depending on beam length) * Beam lengths 6 1/2-13 ft (2-4 m) * Beam types available rigid, articulated, skirted * Beam materials available rigid: aluminum and wood articulated & skirted: aluminum * Power supply 115 VAC or 230 VAC -10% to +6%; 60Hz * Motor horsepower 1/3 hp * Ambient temperature range -33oF to 165oF (-36oC to 74oC) * Hydraulic locking positions opened and closed * Cabinet dimensions (l x w x h) 6 3/4 x 10 9/16 x 39 in. (17.2 x 27 x 99 cm) * Weight (approx.) 100 lb (45.5 kg) * Electric motor single phase, bi-directional * Anti-crush system hydraulic valves (by-pass) * Features keyed manual release in the event of power failure |
| * Dedicated Logic - The electronic intelligence of the 615 offers six types of control logics, including automatic and semiautomatic. * Easy to Maintain - Maintenance could not be simpler and diagnostic checks are immediate thanks to the input LEDs. Like all FAAC hydraulic operators, the 615 is completely self-contained for reliable operation. * Standard Features - The 615 has many standard features, including hydraulic anti-crushing safety, hydraulic locking so that the beam remains secure in the opened and closed positions, and a manual release with a personalized key. Also standard is the versatile 455 D control panel. |
| MODEL 615 FEATURES INCLUDE: Adjustable hydraulic pressures to control swing Hydraulic open & closed locking positions External key-operated manual release Simple interface with revenue control system Powder coated steel cabinet Versatile model 455D control panel Quiet operation ALL 615 MODELS REQUIRE FOLLOWING: Assembly of the beam Assembly of the beam's counterbalancing system OPERATING LOGISTICS: E - Garage door-like logic (signal to open signal to close) A - Automatic logic (one signal opens the gate and closes it after a timed pause) S - Security logic (much like the A logic, usefull in high traffic applications to counter tailgating) EP - Semi automatic logic (signal to open the gate, second to stop it, third reverses gate) B - Manned, pulsed logic (designed for guard station use, requires 3-button switch (pulsed) to open, close and stop the gate) C - Manned, constant logic (similar to B logic, but 3-button switch requires constant pressure on each button) |
